Product Parameter
Item | Unit | Parameter values |
Engine model | / | LR6M205-40 |
Engine manufacturer | / | Yituo (Luoyang) Diesel Engine Co., Ltd |
Engine type | / | Inline, Four stroke |
Engine calibration power | kw | 132.4 |
Engine calibration speed | r/min | 2200 |
External dimensions (length x width x height) | mm | 5070*2420*3055 |
Wheelbase | mm | 2550 |
Track width (front wheel) | mm | 1620,1800,1960,2040 |
Track width (rear wheel) | mm | 1560~2025 |
Minimum ground clearance | mm | 455(Front axle oil drain bolt) |
Fuel tank capacity | liter | 200 |
Tire specifications (front wheel) | / | 14.9-26 |
Tire specifications (rear wheel) | / | 18.4-38 |
Minimum usage quality | kg | 5900 |
Transmission | / | 16+8 |
Driving speed | km/h | 31 |
Power output speed | r/min | 760/850 |
Tractor Main Features and Advantages
Basic configuration:
It is equipped with diesel engine, 16 + 8 shift, hydraulic steering, front wheel 14.9-26, rear wheel 18.4-38, vertical double-cylinder strong pressure lifter and three groups of hydraulic output.
Engine
With the diesel engine, the power is surging, the speed is fast, the durability is reliable and the fuel consumption is low.
Control system
1. Modern side control system, simple and efficient operation.
2. Luxury cab, air conditioning, spacious and comfortable, reduce driving fatigue.
3. The turning radius is small and the steering is flexible, creating the ultimate control of the whole vehicle.
Transmission system
1. 16 + 8-speed gearbox, multi-gear adjustable, reasonable speed setting. Meet different working conditions and have strong adaptability.
2. High efficiency, low fuel consumption, achievement operation income small expert.
3. The road speed reaches 31 km/H, and the advantages of transfer and transportation are significant.
4. Independent double-acting clutch with excellent performance, high reliability and long service life.
Hydraulic system
1. Perfect lifter system, standard vertical double-cylinder strong pressure lifter, strong lifting force up to 31.8 KN, wide range of supporting machines and tools, comfortable operation and high efficiency.
2. The hydraulic pipeline oil seal is designed with imported structure, with ultra-long service life to protect efficient operation.
3. Independent hydraulic oil tank + oil tank radiator to ensure continuous and normal operation of the main engine.
Hang
Our company(Legend)'s special reinforced suspension, the strength is greatly improved, the reliability is far more than peers
Harness
Waterproof harness, no poor contact for 50 hours, safe operation.
Adaptability
The ground clearance is up to 455 mm, with super trafficability, unimpeded and worry-free operation.
